Drone & UAV assembly materials
Adhesives &
silicones
for drones & UAVs
Structural bonding · Thermal management · Potting · Sealing
PROSTECH supplies Momentive silicones and Permabond engineering adhesives for drone, UAV, urban air mobility and VTOL production in Vietnam. Bond carbon-fibre frames and motor magnets, cool batteries, protect electronics and seal enclosures, from assembly to maintenance and repair.
Momentive SiliconesPermabond Adhesives
40+drone-ready grades
260 °Csilicone max temp
<1 sUV cure (UV643)
ASTM E595 low outgassingRoHS compliantUV, heat & room-temperature cureBonds composites, metals & plasticsSamples & on-site support
Why materials matter
Lighter, tougher,
Lighter, tougher,
longer flight life
As drones get lighter and more energy efficient, adhesives replace fasteners, and every board, battery and sensor must survive vibration, heat, moisture and UV.
Thermal management
Silicone RTVs and thermally conductive adhesives move heat away from batteries, ESCs and boards across a wide temperature range.
Vibration & stress reduction
Flexible materials secure components and absorb impact and vibration from motors and propellers.
Weatherproofing
Low-shrinkage silicones seal cases, gaskets and connectors and protect PCBs with long-term adhesion.
Lightweight structural bonding
Toughened epoxies and acrylics bond carbon fibre, metals and plastics while spreading stress evenly.
Sensor & display optics
Hardcoats protect polycarbonate lenses and improve LIDAR transmission; InvisiSil optically clear silicones make rugged, sunlight-readable displays.
Low outgassing
Silicones that meet or exceed ASTM E595 protect optics and sensors from volatile contamination at high altitude.
Selection guide
Drone application map
Each number marks a point on the drone that needs a specialist material. Click a product code for its full page and datasheet.
1Composite frame & structure
ET5428 · ET5429 · ET5424 · ET5422Toughened Permabond epoxies with high peel strength replace rivets on carbon-fibre and composite airframes.2E-motor magnet bonding
TA437 · TA4590 · ES566Permabond acrylics and one-part heat-cure epoxy hold magnets at up to 200 °C.3Motor bearings
HM162Permabond retaining compound for bearings in housings or on shafts, rated to 200 °C.4Threadlocking nuts & bolts
HM129 · MM115Permabond anaerobics stop vibration loosening; permanent or removable strength.5Battery thermal management & potting
TN3085/88 · XE11-B5320 · TIA208R · RTV133 · MT3836Momentive thermal adhesives, battery potting and flame-suppressant silicone; Permabond MT3836 is thermally conductive and fire-retardant.6PCB encapsulation & vibration damping
TUV7130 · TSE3663 · MT382UV-cure Momentive encapsulant and silicone potting; flexible Permabond hybrid for electronics.7Connectors & cables
TN3305 · TSE397 · TSE3251Momentive silicones that waterproof pin connectors without corroding contacts.8Camera, gimbal & sensors
UV639 · TSE3051 · TSE322Permabond UV639 bonds camera lenses in seconds; Momentive gels and sealants protect sensors.9Enclosure & O-ring sealing
RTV100 Series · TN3005 · TN5015 · TN8000Momentive room-temperature-cure RTV silicones with UV and ozone resistance.10EMI shielding & heat transfer
TIA241GF · CXE16-0226B · LTR3292 · ET5441Momentive gap filler, EMI paste and ASTM E595 thermal adhesive; Permabond thermally conductive epoxy.11Plastic & 3D-printed parts
TA4550 · TA4551 · 712Permabond acrylics and cyanoacrylate for nylon, ABS and printed parts such as prop guards.12Composite repair
UV643 · ET503Permabond UV643 cures in under 1 second with LED; ET503 epoxy for field repairs.High-performance silicones
Momentive for drones
Properties held from −115 °C to 260 °C, flexible at extreme low temperatures, strong dielectric and thermal insulation, UV and ozone resistant, room-temperature cure.
| Product | Description | Appearance | Cure | Viscosity (Pa·s) | Hardness | Tensile (MPa) |
|---|---|---|---|---|---|---|
| Battery management | ||||||
| TUV7130 | PCB encapsulation / vibration damping | Translucent | UV | 21 | 31 (Type E) | – |
| TN3085/88 | Thermal adhesive | Grey / White | CC | – | 46 (Type A) | 2.3 |
| XE11-B5320 | Thermal adhesive | White | CC | – | 83 | 4.1 |
| TIA208R | Battery potting | Black | CC | 4.2 | 40 (Type A) | 1.6 |
| RTV133 | Flame suppressant | Black | CC | – | 45 (Shore A) | 0.7 |
| Connectors | ||||||
| TN3305 | Pin connector waterproofing | Clear / White / Black | CC | 47 | 14 (Type A) | 1.5 |
| TSE3251 | Heat-cure adhesive | White | AC | 8.5 | 16 (Shore A) | 0.7 |
| TSE397 | Non-corrosive adhesive sealant | Clear / Black / White | CC | 50 | 13 | 1.2 |
| EMI shielding & thermal | ||||||
| TIA241GF | Gap filler | Blue | AC | 130 | 45 (Type E) | 0.2 |
| CXE16-0226B | EMI | Black paste | CC | 430 | 44 (Shore A) | 1.9 |
| LTR3292 | Thermal adhesive (ASTM E595) | Grey | AC | 12 | 83 (Shore A) | 2.6 |
| O-ring & case sealing | ||||||
| RTV100 Series | Adhesive sealants | Various | CC | – | 20–30 (Shore A) | 3.0 |
| TSE322 | Adhesive sealant | Light blue | AC | 110 | 45 (Type A) | 3.4 |
| TN3005 | Adhesive sealant | Clear / White / Black | CC | – | 22 (Type A) | 1.8 |
| TN5015 | Adhesive sealant | Grey | CC | – | 50 (Shore A) | 4.5 |
| TN8000 | Adhesive sealant | White / Black / Grey | CC | – | 33 (Type A) | 2.2 |
| Sensor coating & potting | ||||||
| TSE3051 | Gel | Transparent | AC | 0.7 | – | – |
| TSE3663 | Potting | White (A) / Pale yellow (B) | CC | 4000 | 41 (Type A) | 1.4 |
| TIA222G | Potting | Grey | CC | 20 | 45 (Type E) | – |
| TIA350R | Potting | Grey | AC | 67 | 77 (Type A) | 1.6 |
AC = addition cure · CC = condensation cure. Typical values, not for use as specifications.
Engineering adhesives
Permabond for drones
Lightweighting, structural bonding and sealing, impact and vibration resistance, fire-retardant and thermally conductive options, RoHS compliant, with many cure speeds and methods.
| Product | Description | Typical application | Colour | Gap | Handling time | Shear (steel) | Temp. range |
|---|---|---|---|---|---|---|---|
| Anaerobic: threadlocking & retaining | |||||||
| MM115 | Prevents loosening, controlled torque, non-drip | Locking nuts & bolts | Blue | 0.15 mm | 10 min | 10 N/mm² | −55 to 150 °C |
| HM129 | High-strength threadlocker, tamper and vibration resistant | Locking nuts & bolts permanently | Red | 0.15 mm | 10 min | 17 N/mm² | −55 to 150 °C |
| HM162 | Permanent high-strength bond, high-temperature resistant | Bearings into housings or onto shafts | Green | 0.2 mm | 5 min | 30 N/mm² | −55 to 200 °C |
| Cyanoacrylate | |||||||
| 712 | Instant bond, excellent environmental resistance | Plastic & 3D-printed parts | Transparent | 0.15 mm | 25 s | 19–24 N/mm² | −55 to 120 °C |
| Epoxy | |||||||
| ES566 | One-part heat cure, no mixing, strong at high temperature | Magnet bonding in electric motors | Grey | 2.0 mm | 10 min at 150 °C | 5–10 N/mm² | −40 to 180 °C |
| ET503 | Two-part, tough, enhanced environmental resistance | Composite repair, electronics ruggedization | White / Light grey | 1.0 mm | 6 min | 20–26 N/mm² | −40 to 100 °C |
| ET5422 | Toughened, ultra-high peel strength | Structural composite assembly, e-motor magnets | Blue | 5.0 mm | 16 h at 23 °C | 30–38 N/mm² | −55 to 120 °C |
| ET5424 | High temperature resistance after low-temperature cure | Structural composite assembly | Grey / Black | 3 mm | 4 h | 20–25 N/mm² | −55 to 230 °C |
| ET5428 | Toughened, high peel strength, rapid cure | Structural composite assembly | Off-white (black available) | 5.0 mm | 30–45 min | 28–34 N/mm² | −55 to 120 °C |
| ET5429 | Composite bonding grade, longer pot life | Structural composite assembly | Black / Yellow | 5.0 mm | 6–10 h | 23–28 N/mm² | −55 to 120 °C |
| ET5441 | High temperature resistant, thermally conductive | Electronics bonding, thermal management | White / Dark grey | 2.0 mm | 8 h | 20–25 N/mm² | −55 to 200 °C |
| Two-part hybrid | |||||||
| MT382 | Flexible, absorbs impact and vibration | Sealing, potting & encapsulating electronics | Black / Yellow | 0.5 mm | 105–120 min | 4–7 N/mm² | −40 to 120 °C |
| MT3836 | Flexible, thermally conductive, fire-retardant | Electronics bonding, thermal sealing | White / Yellow | 5.0 mm | 2–3 h | 2–2.5 N/mm² | −40 to 120 °C |
| Structural acrylic | |||||||
| TA437 | High temperature resistance, high bond strength (with Initiator 41) | Bonding electric motor magnets | Orange | 0.5 mm | 1–3 min with initiator | 14–20 N/mm² | −55 to 200 °C |
| TA4590 | No-mix with Initiator 44, rapid cure, acid-free | Bonding electric motor magnets | Blue | 0.5 mm | 30–60 s | 20–25 N/mm² | −55 to 165 °C |
| TA4550 | Multipurpose, bonds nylon, plastics, metals, composites | 3D-printed plastic bonding & sealing | Transparent / Green | 5.0 mm | 5–6 min | 27–30 N/mm² | −55 to 100 °C |
| TA4551 | As TA4550 with longer open time and nozzle life | 3D-printed plastic bonding & sealing | Red-violet / Transparent | 5.0 mm | 10–15 min | 30 N/mm² | −55 to 100 °C |
| UV curable | |||||||
| UV639 | Fast UV cure, hard surface | Camera lens bonding | Transparent | – | 5–10 s (70 W lamp) | >7 N/mm² (PETG) | −55 to 120 °C |
| UV643 | Ultra-fast UV cure, bonds many plastics | Clear plastic bonding, composite repair | Pale yellow, clear when cured | – | <1 s (LED) | >13 N/mm² (PC) | −55 to 120 °C |
Typical values. Packs from 10 ml bottles to 400 ml dual cartridges; larger packs on request. Always check the latest TDS.
Scope
Substrates & beyond the airframe
Bonds a wide range of materials
Carbon fibreCompositeFRP / GRPHoneycombLaminatePhenolicAluminiumTitaniumSteelZincMagnetsFerritePCBABSAcrylicNylonHDPE / LDPEPolypropylene3D-printed plasticsRubber
Beyond the drone body
Remote controllersDisplay optical bonding, enclosure sealing, waterproof connection points, battery thermal management, EMI shielding.
VR / FPV headsetsDisplay optical bonding, vibration damping, stress reduction, enclosure sealing.
UAM & VTOLLarge composite structures, battery assembly, e-motor magnet bonding.
SatellitesThermal shield and PV bonding, thermally conductive materials, potting, avionics coating.
See all applications in the Drones and UAVs industry section, or browse Momentive and Permabond products.
How we work
From selection to
From selection to
production line
1Tell us the jointSubstrates, gap, operating temperature, cycle time and any certification you need.
2Material selectionPROSTECH engineers shortlist Momentive and Permabond grades for each point on your drone.
3Samples & testingSamples for adhesion and reliability trials on your own parts and line.
4Process supportOn-site help with dispensing, mixing, UV and heat curing, plus TDS and SDS documents.
FAQ
Questions about drone adhesives
Which adhesive should I use to bond a carbon-fibre drone frame?
Toughened two-part epoxies give the best balance of strength and peel resistance on carbon fibre and composites. Permabond ET5428 cures in 30–45 minutes for fast production, ET5429 gives a longer pot life for large assemblies, ET5422 has the highest peel strength (30–38 N/mm² shear on steel) and ET5424 withstands up to 230 °C.
How do I bond magnets in drone motors?
Permabond TA4590 with Initiator 44 fixtures in 30–60 seconds without mixing, TA437 with Initiator 41 handles up to 200 °C, and ES566 is a one-part heat-cure epoxy that needs no mixing and cures in 10 minutes at 150 °C.
What materials help manage heat in drone batteries and electronics?
Momentive thermal adhesives TN3085/88 and XE11-B5320, TIA208R battery potting, TIA241GF gap filler and LTR3292 thermal adhesive move heat away from cells and boards. Permabond ET5441 and MT3836 are thermally conductive adhesives; MT3836 is also fire-retardant.
How can I waterproof drone connectors and enclosures?
Momentive TN3305 is designed for waterproofing pin connectors, and TSE397 is a non-corrosive sealant that is safe near metal contacts. For enclosure and O-ring sealing use room-temperature-cure RTV silicones such as the RTV100 series, TN3005, TN5015 or TN8000, which resist UV and ozone.
What is ASTM E595 low outgassing and why does it matter for drones?
ASTM E595 measures how much volatile material a cured material releases under vacuum and heat. Low-outgassing silicones such as Momentive LTR3292 reduce the risk of vapours fogging lenses or contaminating sensors at high altitude.
Which adhesive bonds camera lenses on a gimbal?
Permabond UV639 cures in 5–10 seconds under a 70 W UV lamp and forms a hard, clear bond for camera lenses. For sealing and protecting sensors, Momentive TSE3051 gel and TSE322 sealant are commonly used.
Can these adhesives bond 3D-printed and low-surface-energy plastics?
Permabond TA4550 and TA4551 acrylics bond nylon, plastics, metals and composites, and 712 cyanoacrylate bonds printed parts in about 25 seconds. For polypropylene and polyethylene, PROSTECH can advise on a primer or surface treatment.
Where can I buy Momentive and Permabond drone materials in Vietnam?
PROSTECH supplies Momentive silicones and Permabond adhesives in Vietnam, with samples, technical advice and on-site process support. Use the contact form on this page to request a quote.
Building or repairing drones?
Send a drawing or describe where you need to bond, seal or cool. PROSTECH application engineers will recommend materials and arrange samples.
Request a quote
for drone materials
for drone materials
Tell us the product codes or the application (substrates, temperature, quantity). We reply with recommendations, pricing and sample availability.
Typical properties are compiled from Momentive Performance Materials and Permabond Engineering Adhesives literature and are not specifications. Users should test materials under their own conditions. Momentive, InvisiSil and Permabond are trademarks of their respective owners.
