  1. WATER CONTACT INDICATOR TAPES

Designed to provide clear, accurate evidence of liquid water intrusion. Fast and Accurate water detection for Electronics

Water Contact Indicator Tapes are self-adhesive film/paper laminate constructions that change color from white to red when contacted by liquid water. They provide a fast, accurate and easy way to positively detect water intrusion into sensitive electronic devices, including mobile handheld devices, e-books, digital cameras and laptop computers. They are especially useful for providing evidence of water damage during shipment or when validating consumer warranty claims.

Our Materials Solutions including: Details

3M Water Contact Indicator Tape 5557 is the workhorse of this product family and offers a comprehensive package of environmental stability, indication speed, total caliper, and printability.

3M Ultrathin Water Contact Indicator Tapes 5558 and 5559 offer a thinner total caliper, where tight geometries dictate a very low thickness water indicator product.

3M Water Contact Indicator Tape 5557NP is a new addition to this family. The product retains most of the premium attributes of 5557 indicator tape while offering enhanced indication speed through the removal of the top film layer.

3M Water Contact Indicator Tape 5559i has the same attributes as tape 5559 except the adhesive is on the top side for viewing through transparent substrates, which may be used in certain product designs.

  1. FLEXIBLE CIRCUITRY BONDING SOLUTIONS

Make a strong connection – Optimize performance and design with right tape for your FPC application

Flexible Printed Circuits (FPC) are in virtually everything.

Flex bonding is not a one-size-fits-all solution. The success of your intricate design requires a specific, reliable FPC bonding method. Our Flexible Circuitry Bonding Solutions give you the exact tape for your exact need — so you can create without limits.

GENERAL ELECTRONICS

AUTOMOTIVE

APPLIANCES AND MORE

Our Materials Solution and Recommended Surface Application: Details

3M Adhesive Transfer Tape 467MP (0.06mm)

3M Double Coated Tape 9492MP (0.05mm)

Standard solution for bonding metal/FR4 to polyimide

3M Adhesive Transfer Tape 9471LE (0.06mm)

3M Double Coated Tape Double Linered 93005LE (0.05mm)

Robust solution for bonding hard-to-bond material (PC/ABS/PA/PET/powder-coated metal) to polyimide

3M Adhesive Transfer Tape 9471LE (0.06mm)

Anti-lifting solution for curved FPC bonding

3M Adhesive Transfer Tape F9460PC (0.05mm)

High temperature resistant (up to 125˚C/257˚F) FPC bonding

3M Ultra High Temperature Double Coated Tape 9077 (0.05mm)

3M Ultra High Temperature Double Coated Tape 9079 (0.05mm)

Reflow FPC process (up to 260˚C/500˚F)

3M Ultra Clear Double Coated Tape UCT-30 (0.03mm)

3M Ultra Clear Double Coated Tape UCT-10 (0.01mm)

Thin solution (<0.05mm) for FPC bonding><0.05mm) for FPC bonding

3M Electrically Conductive Adhesive Transfer Tape 9707 (0.05mm)

3M Electrically Conductive Double-Sided Tape 9711S-30 (0.03mm)

3M Electrically Conductive Double-Sided Tape 9711S-50 (0.05mm)

3M XYZ-Axis Electrically Conductive Adhesive Transfer Tape 9720 (0.03mm)

3M Electrically Conductive Double-Sided Non-Woven Tape 9750 (0.055mm)

Conductive FPC bonding

3M Thermal Bonding Film 583 (0.05mm)

Thermal bonding film for FPC bonding
