Huntsman Araldite CW 2243-2 L / Aradur HY 842

Product code: Huntsman Araldite CW 2243-2 L / Aradur HY 842

Manufacturer: Huntsman

Package size:

Shelf Life:

Huntsman Araldite CW 2243-2 L / Aradur HY 842 is 2-part epoxy adhesive used for encapsulating.

Optimally filled casting system for processing and curing at slightly higher temperatures.

FEATURES:

  • Low viscosity.
  • Flexible castings.
  • Good thermal shock resistance.
  • Flammability: UL 94 V-0 (6 mm).
  • Railway EN 45545-2, R22 HL1 / R23 HL2

APPLICATIONS:

  • Small transformers.
  • Suppressor chokes.

PROCESSING METHOD:

Casting; vacuum casting.

MIXING RATE:

Araldite CW 2243-2 L / Aradur HY 842 = 100/20





Araldite CW 2243-2 L

Modified, solvent free epoxy resin containing an inorganic filler.

Viscosity at 25°C ISO 2555 mPa*s 4000 – 12000*
Specific gravity at 25°C ISO 2811 g/cm³ 1.610-1.650
Appearance Visual   Blue, viscous liquid

Aradur HY 956 EN

Formulated, low viscosity polyamine hardener.

Viscosity at 25°C ISO 3219 mPa*s 400 – 700*
Specific gravity at 25°C DIN 51757 g/cm³ 0.95
Appearance Visual   Clear liquid*

TDS: Download PDF

MSDS: Fill your information to receive file:
