UV5102 – VGA Chip Photo-curing Adhesive for Connector Reinforcement

  • Product code:
  • Manufacturer: Gluditec
  • Package size:
  • Shelf Life: 8 months

Request Quote Request Sample

UV5102 Is photo-curing adhesive designed for the bonding of computer connector PVC/PET/PI and metal connector. The connector will not peel off and short-circuit when the connector is bending. Showing excellent hardness and surface drying, this product will not bond hands or dust. This resin can fast-cure for encapsulating of electronic field

TYPICAL UNCURED PROPERTIES

PropertiesUV5102
CompositionUV adhesive
AppearanceLiquid
ColorOpaque
Viscosity*
*25°C, S14 100rpm, cps		4,500 ~ 6,100
Viscosity
*25°C, S14 10rpm, cps		24,000 ~ 38,000
Thixotropic Index4.5~6.0
Specific Gravity @25°C1.10
Solvent Content, %0

* This value is for reference. Please refer to COA for the actual value.

TYPICAL CURING PROPERTIES*

PropertiesUV5102
Recommended Wavelength, nm310~365
Minimum Light Intensity, mW/cm²> 50
Minimum Light Energy, mJ/cm²1,000~2,000



TYPICAL CURED PROPERTIES

PropertiesUV5102
Glass Transition Temp., (TMA), ºC86
CTE* (<Tg), μm/m/ºC110
CTE* (>Tg), μm/m/ºC195
Durometer Hardness ASTM D2240-03, Shore D76
Shear Strength, PC vs. PC, kgf cm²63
Elongation, %56
Breaking Value, N/mm²23
Tensile strength, N/mm²18
Thermal Conductivity, W/mK0.18
Volume Resistivity, @500V, Ohm-cm5.61*10^14
Surface Resistivity, @500V, ohm1.76*10^15
Dielectric Constant/ Dielectric loss @100Hz3.4721/0.0757
Dielectric Constant/ Dielectric loss @1KHz3.3871/0.0506
Dielectric Constant/ Dielectric loss @10KHz3.1178/0.0513
Dielectric Constant/ Dielectric loss @100KHz3.2915/0.1733

TDS:Download

Get MSDS
