Artificial Graphite Pad PT86

  • Product code: PT86
  • Manufacturer:
  • Package size:
  • Shelf Life:

Request Quote Request Sample

PT86 Artificial Ultra Thermal Conductive Graphite Pad is highly oriented pyrolytic graphite sheet with high thermal conductivity. A heat source can reduce temperature by spreading heat over the PT86. It is flexible and has features of ultra-thin and high EMI shielding effect.

FEATURES:

  • Ultra high thermal conductivity,electrical conductivity and EMI shielding effect effect
  • Flexible, and bendable
  • Ultra thin; Low mass; Environmental friendly
  • Low thermal resistance

APPLICATIONS:

Mobile phone, Laptops, Set-top box, LED back light, PDP/LCD/OLED screens Ultra bright LED, Digital camera, Digital video camera, NIC, Projector, Handheld device etc.



Properties PT86 Unit Tolerance Test Method
Thermal Conductivity

XY axis: 1500

Z axis: 5

 W/mK

+/-100

+/-0.5

AC calorimeter

Laser flash
Thickness 25 μm – Micrometer
Color Black – – Visual
Flame Rating V-0 – – UL 94
Thermal Diffusivity 8.5 cm² / S +/-0.5 AC calorimeter
Density 2.1 g / cm3 +/-0.1 Archimedes law
Electrical Conductivity >13000 S/cm – JIS K7194
Bending Test 10000 times – –
Working Temperature -40~400 °C – AC calorimeter
Heat Capacity (SHC) 0.895 J/g-K – –



TDS:Download

Get MSDS
