PTUV-1 Photo-curing Adhesive for PCB Sealing and Bonding

  • Product code: PTUV-1
  • Manufacturer: Everwide
  • Package size: 1 kg
  • Shelf Life: 12 months

Request Quote Request Sample

PTUV-1 is a photo-curing adhesive and designed for computer connector PVC/PET/PI and PCB bonding. This product has good surface dryness. Cured resin is not tacky and dust-proof. This product is able to fast curing under UV light and suitable for encapsulating in the electronic field.

FEATURES:

  • This resin is suited different plastics bonding.
  • This product will not destroy by external force with high strength and fracture energy.
  • This resin is also suited for encapsulation.
  • This product complies to the 2011/65/EU RoHS regulations.



TYPICAL UNCURED PROPERTIES

Appearance Liquid
Color Opaque
Viscosity 25oC, S14 50rpm, cps 19,000~25,000
Specific Gravity@26.6oC 1.0822
Refractive Index nD@25.6oC 1.4749
Certificate RoHS
Solvent Content, % 0

TYPICAL CURING PROPERTIES

Recommended Wavelength, nm 310~400
Minimum Light Intensity, mW/cm2 > 50
Minimum Light Energy, mJ/cm2 1,000~2,000

TDS:Download

Get MSDS
