3M™ Temflex™ Rubber Splicing Tape 2155

  • Product code: 2155
  • Manufacturer: 3M
  • Package size: 6 m, 6.7 m
  • Shelf Life: 3 years
Request Quote Request Sample

3M™ Temflex™ Tape 2155 is a 30 mil, general purpose, highly conformable, electrically insulating, low voltage rubber splicing tape. The self fusing tape is designed to offer guaranteed performance when used with solid dielectric cable insulations and has a liner, which will not stick to the tape upon unwind. It withstands a wide temperature range of 176 °F (80 °C).

3M™ Temflex™ Splicing Tape 2155 with self fusing rubber backing, has rubber resin adhesive that offers optimized adherence. This tape is designed for low voltage electrical insulating and moisture sealing applications. It maintains the flexibility over a wide range of temperatures. Electrical insulating tape finds application in bolted connections, service drops, lightning connections, ground rod connections and motor leads. UL Listed and RoHS 2011/65/EU Compliant.

Features

• UL listed, File E129200
• Compatible with solid dielectric cable insulations
• Self-fusing tape
• Flexible over a wide temperature range

Applications
• Bolted connections
• Service drops
• Lightning connections
• Ground rod connections
• Motor leads

Adhesive Type

Non-adhesive

Application

Electrical Maintenance, Insulation

Backing (Carrier) Material

Rubber

Backing (Carrier) Thickness (Metric)

0.76 mm

Brands

Temflex™

Case Quantity

12 Rolls

Dielectric Strength

600 V/mil

Elongation at Break

700.0 %

Features

Self-sticking, Vulcanizing

Maximum Operating Temperature (Celsius)

80 ℃

Maximum Operating Temperature (Fahrenheit)

176 ℉

Minimum Operating Temperature (Celsius)

0 ℃

Shelf Life

3 Year

Specifications Met

RoHS 2011/65/EU, UL Listed

Tape Grade

General Use

Tensile Strength (Imperial)

300.0 lb/in

Tensile Strength (Metric)

2068.4 kPa

Total Tape Thickness without Liner (Imperial)

30 mil

Total Tape Thickness without Liner (Metric)

0.76 mm

Units per Case

100.0

Voltage Rating

600 V

eClass 14 Classification Group

27140708

TDS:Download

Get MSDS
