3M™ 1182 Tape consists of a 1-ounce deadsoft copper foil backing that is coated on both sides with a unique electrically conductive pressuresensitive acrylic adhesive.
FEATURES
- Dead soft 1-ounce (1.4-mil) copper foil backing for good shielding effectiveness, soldering and converting (slitting and die cutting).
- UL recognized flame-retardancy per UL 510 for applications needing this property.
- Conductive particles in the adhesive on both sides provides low contact resistance between substrates and the backing to drain static charge.
- Acrylic pressure-sensitive adhesive has good resistance to heat, oxidation, solvents and oils.
- Removable liner on both sides makes it easy to handle and die cut complex shapes.
- There are both standard and custom roll widths and lengths to meet a variety of application needs.
APPLICATIONS
- EMI Shielding
- Grounding
- LV Conductor
Property | Values |
Backing thickness | 1.4 mil (0,04mm) |
Total thickness (backing plus adhesive on both sides) | 3.5 mil (.088mm) |
Breaking strength | 25 lb./in (44 N/10mm) |
Adhesion to steel | 35 oz/in (3,8 N/10mm) |
Electrical resistance through adhesive | 0.010 ohm |
