3M™ Double Coated Urethane Foam Tapes are conformable foams that offer high shear strength with a high temperature holding acrylic adhesive system for bonding to various types of surfaces for mounting, joining and holding.
FEATURES
- The natural colored urethane foam tape products vary in color from white to light The color will change to light yellow upon exposure to sunlight (ultraviolet radiation). This color change is normal and does not affect tape performance.
APPLICATIONS
- General interior and exterior mounting applications where the tape will be protected from the environment
- Mount interior signs and nameplates
- Mounting dispensers and air fresheners
- Bond acoustic panels to walls
- Attach wire clips to wall surfaces
- Mount corner protectors
Typical Physical Properties
|
Attribute Name |
Value |
|
Color |
Natural |
|
Adhesive Type |
100 |
|
Foam Density |
175 kg/m³ (11 lb/ft³) |
|
Adhesive Carrier |
Polyurethane Foam |
|
Attribute Name |
Value |
|
Thickness Tolerance |
1.142 to 2.03 mm (45 to 80 mil) |
|
Thickness: Nominal |
1.6 mm (62.5 mil) |
|
Liner Thickness |
0.08 mm (3 mil) |
|
Primary Liner Color |
Green Plaid |
Typical Performance Characteristics
|
Temperature |
Value |
|
22 °C (72 °F) |
1,500 g |
|
49 °C (120 °F) |
1,000 g |
|
66 °C (150 °F) |
750 g |
|
93 °C (200 °F) |
750 g |
|
Attribute Name |
Test Method |
Value |
|
Normal Tensile |
ASTM D897 |
345 kPa (50 lb/in²) ¹ |
|
Attribute Name |
Temperature |
Value |
|
Short Term Temperature Resistance |
|
193 °C (380 °F) ¹ |
|
Long Term Temperature Resistance |
|
104 °C (220 °F) ² |
|
Cold Flex |
-30 °C (-20 °F) |
No cracking when flexed around a 1/4 in (6.4 mm mandrel). |
|
Attribute Name |
Value |
|
Elongation at Break |
100 % |
|
Tensile Strength |
965 kPa (140 lb/in²) |
Typical Environmental Performance
|
Attribute Name |
Value |
|
Solvent Resistance |
No apparent degradation when exposed to splash tests of most hydrocarbon solvents. |
|
UV Resistance |
No apparent degradation when exposed to 7 days in U.V. chamber. |
Electrical and Thermal Properties
|
Attribute Name |
Test Method |
Value |
|
Dielectric Strength |
ASTM D149 |
8 to 12 V/μm |
|
Thermal Conductivity |
|
0.062 W/m/K (0.036 (btu-in)/(h-ft²-°F)) |
Available Sizes
|
Attribute Name |
Value |
|
Available Width |
1168 mm (46 in) |
|
Maximum Length |
91 m (100 yd) |
|
Normal Slitting Tolerance |
±0.8 mm (±1/32 in) |
|
Note |
Subject to Minimum Order Requirements |
|
Standard Roll Length |
32.9 m (36 yd) |
