This machine has a photoelectric tracking correction system, the tension of the rewinding and unwinding is controlled by a magnetic powder clutch, the host frequency conversion speed regulation, the up and down movement of the rubber roller is controlled by the cylinder, and it can be laminated and slit at the same time, and it can also be laminated or slit separately. Accurate cutting, fast cutting speed, convenient operation and maintenance, etc.
Optical material slitting machine, laminating, slitting, and rewinding two materials. With hydraulic loading. Specially used for the slitting of PET, OCA, AB glue, PvC, release film, brightness enhancement film, diffusion film, and reflective film. The tension control is uniform and adjustable, which meets the requirements of rewinding and unwinding, ensuring consistent material tightness, frequency conversion speed regulation, maintaining acceleration and smooth operation, good anti-scratch function, ensuring no mechanical scratches designed, automatic correction of ultrasonic servo motor, ensuring There is no left-to-right drift in product receipts.
FEATURES:
Laminating function
EPC (edge positioning control) device: Ultrasonic sensor
Waste discharge function
Magnetic brake and clutch
The length counting function automatically stops after it reaches the length you set.
2 rewinding inflatable shafts, easy for unloading materials.
APPLICATIONS:
1. It is applicable for the slitting tooling of industrial adhesive tape, electronic material, protective film, copper foil, aluminum foil, OPP, PE, PVC, sheet, cloth, etc.
2. This machine is widely used in industries such as printing, packing, electronics, leather, clothesmaking, plastic, etc.
CHARACTERISTICS AND FUNCTIONS
1. This machine is slitting equipment of high precision and high sensitivity, with an inflatable bearing used for feeding and receiving materials.
2. An imported magnetic powder clutch is adopted to control the tension.
3. An imported gas-sensitive device is adopted to detect the rectification of rolling, with fully automatic hydraulic rectification control.
4. Automatic detection, rectification, and metering can be realized.
5. It is characterized by accurate slitting, fast slitting speed, ease of operation, and maintain
MAIN TECHNICAL PARAMETERS
| Model | HX-650FQ |
| Max Feeding Width | 650mm |
| Main Engineer Power | 2.2kW |
| Speed | 80m/min |
| Size | 2400 x 1700 x 1300 mm |
| Weight | 1000kg |
| Rewinding Diameter | 600mm |
| Winding Diameter | 450mm |
| Precision | ±0.1mm |
| Power | 220V 50Hz |
| The minimum slitting width | 8-25mm |
| Material thickness range | 0.05 ~ 3mm |
| Tolerence | 0.2mm |
| Precision | 0.1mm |
