TG-LH-FBPE-80U is a low viscosity, flame retardant and two-part flexible black potting compound based on epoxy resins. When fully cured the surface is glossy, blush free and hard. It has very good scratch and water resistance. This system has enhanced adhesion and wets glass, ceramics, most plastics and metals well. The mixed epoxy has low viscosity to ensure good flow, good seepage into every corner and minimal trapping of bubbles.
FEATURES
- UL VO
APPLICATIONS
- Potting epoxy for electrical and electronic devices
| Property | TG-LH-FBPE-80U | Unit | Test Method | ||
| Part A Resin | Part B Hardener | Mixed | |||
| Chemical type | Epoxy | Amine | – | – | – |
| Appearance Black | Liquid | Clear yellowish liquid | – | – | Visual |
| Thermal Conductivity | – | – | 1.8 | W/mK | ISO/DIS 22007 |
| Mix ratio, by weight | 2.0 | 1.0 | – | – | – |
| Shelf life, 25°C | 12 | 12 | – | Month | ASTM F2914 |
| Pot life, 25°C | – | – | 6 | Hour | ASTM F2914 |
| Flame rating | – | – | V-0 | – | UL94 V0 |
| Viscosity, CAP2000+ viscometer, 25°C | 22,200 | 140 | 3,200 | cP | ASTM D1084 |
| Hardness, cured 25°C for 7 days | – | – | 80 | Shore D | ASTM D2240 |
